SMA Male Female Crimp Connector for RG316 RG174 LMR100 Cable

SMA Male Female Crimp Connector for RG316 RG174 LMR100 Cable

Applications
1.Antennas
2.Broadcast
3.radios
4.Electronic test equipment
5.Serial digital and Analog interface
6.Non-professional radio antenna connections

Electrical
Impedance: 50 Ω
Frequency Range: 0-4 GHz with low reflection
Voltage Rating: 500 volts peak
Dielectric Withstanding Voltage: 1,500 volts rms
VSWR: 1.3 MAX
Contact Resistance: Center contact: ≤3mΩ; Outer contact: ≤2mΩ
Durability: 500 Cycles
APPLICABLE STANDARD: IEC169-15  MIL-C-39012

Material
Contact: Brass,goldplated
Insulator: PTFE
Crimp Ferrule: Copper/brass
Temperature Range: TFE insulators: - 65°C to + 165 °C Copolymer of Styrene: - 55°C to + 85°C
