Multiband LTE 4G 5G 5.8G antenna Dual Band Antenna 600-6000Mhz Antenna

Multiband LTE 4G 5G 5.8G antenna Dual Band Antenna 600-6000Mhz Antenna

Electrical Characteristics

. Frequency (MHz) : 600-6000 MHz

. S.W.R. : < 3.0

. Efficiency : 30~50% @ 600-960 MHz

                    45~55% @ 1400-6000 MHz

. Peak Gain : < 3 dBi

. Impedance : 50 ohm

. Polarization : Linear

Mechanical Characteristics

. Cable : O.D. 1.37 mm

. Connector : SMA Male

. Connector Pull Force : > 3.0 Kg

. Cover Material : PC+PT / ABS

. Color : Black

. Material : RoHS Compatible /

          RoHS 2011/65/EU with IEC 62321:2008 Method

Environmental Condition

.Operation Temperature : -30 ~ +65 ºC

.Storage Temperature : -30 ~ +85 ºC
