2.4G 9dBi Omni-directional High Gain SMA Male Antenna

2.4G 9dBi Omni-directional High Gain SMA Male Antenna

A. Electrical Characteristics
Frequency: 2400 ~ 2500 MHz
S.W.R.: <= 2.0
Antenna Gain: 9 dBi ± 0.7dBi
Polarization: Linear
Impedance: 50 Ohm

B. Material & Mechanical Characteristics
Material of Radiator: Cu
Material of Plastic Body: TPE
Hinge: PA+ABS
Cable Type: RG-178
Connector Type: SMA Male
Connector Pull Test: >= 3 Kg
Connector Torque Test: 520~1400 g.cm

C. Environmental
Operation Temperature: - 40 ˚C ~ + 65 ˚C
Storage Temperature: - 40 ˚C ~ + 80 ˚C
